Inconel Condensate Pots

Home > Inconel > Inconel Condensate Pots

Iyle Tube Fittings is a trusted manufacturer and supplier of Inconel Condensate Pots in South Africa. Condensate pots are designed to collect and remove condensate, moisture, or small liquid droplets from steam, gas, or air pipelines, protecting sensitive instruments and equipment. Made from Inconel, a high-performance nickel-chromium alloy, these pots offer excellent corrosion resistance, strength, and durability even in harsh or high-temperature environments. Iyle Tube Fittings ensures each Inconel Condensate Pot is reliable, durable, and easy to install. These are ideal for chemical, petrochemical, oil and gas, and industrial systems requiring safe condensate management.

Inconel Type A Condensate Pot with Zinc Plating Manufacturer South Africa, Inconel Condensate Pot Type B Dealer Johannesburg, Inconel Type C Condensate Pots with 4 Ports Manufacturer Supplier Durban, 600 Inconel Condensate Pots Type A Exporter In Germiston, Inconel Type B Condensate Pot with Galvanized Plating Manufacturer Gqeberha, Inconel Type C Condensate Pot with Red Oxide Coated In South Africa, Cape Town.

Inconel Condensate Pots are made from Inconel, a nickel-chromium alloy known for exceptional corrosion resistance, high strength, and the ability to withstand extreme temperatures. The material resists chemical attack, oxidation, and mechanical wear, ensuring long service life. Condensate pots are precision-engineered to collect and remove moisture from pipelines while maintaining structural integrity under high pressure and temperature. These pots are robust, leak-proof, and reliable, making them suitable for demanding industrial, chemical, petrochemical, and oil and gas applications where protection of instruments and smooth process operation is critical.

Inconel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Inconel Condensate Pots Chemical Composition

Grade	Ni	Cr	Fe	C	Mn	S	Si	Cu
Inconel Condensate Pots	72.0 min	14.0 – 17.0	6.0 – 10.0	0.15 max	1.0 max	0.015 max	0.5 max	0.5 max

Sizing Of Inconel Condensing Pots

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Inconel Condensate Pots Manufacturing Company in South Africa

At Iyle Tube Fittings, we are the largest supplier, manufacturer, and exporter of Inconel Condensate Pots in South Africa, Cape Town. Our advanced manufacturing facilities, strategically positioned in the Cape Town, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Inconel Condensate Pots

Equivalent Grades of Inconel Condensate Pots

STANDARD	UNS	WERKSTOFF NR.	JIS	AFNOR	BS	GOST	EN
Inconel Condensate Pots	N06600	2.4816	NCF 600	NC15FE11M	NA 13	МНЖМц 28-2,5-1,5	NiCr15Fe

Inconel Condensate Pot Type A Price in South Africa, Inconel Type B Condensate Pot with Zinc Plating Manufacturer Supplier in Johannesburg, Alloy 800 Type C Condensate Pots Manufacturer in Durban, Inconel Type A Condensate Pot with Galvanized Plating Price in Germiston, Inconel Type B Condensate Pot with Red Oxide Coated Supplier And Manufacturer in Gqeberha, 601 Inconel Type C Condensate Pot In South Africa, Cape Town.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Inconel Condensate Pots Supplier in South Africa, Cape Town

Iyle Tube Fittings is a leading supplier and stockist of premium Inconel Condensate Pots in South Africa, Cape Town. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Inconel Condensate Pots Uses

Inconel Condensate Pots are used wherever steam, gas, or air pipelines require moisture or condensate removal to protect sensitive instruments and maintain system efficiency. They are commonly applied in chemical plants, petrochemical industries, oil and gas pipelines, power plants, and industrial machinery. Condensate pots ensure safe collection and removal of condensate, preventing corrosion, damage, or inaccurate readings in instrumentation systems. Inconel Condensate Pots are valued for their durability, corrosion resistance, and reliability in high-temperature and chemically aggressive environments. They provide safe, efficient, and long-lasting operation, enhancing reliability and reducing maintenance in critical industrial processes.
