Monel Condensate Pots

Home > Monel >Monel Condensate Pots

Monel Condensate Pots are expertly crafted vessels designed to efficiently collect and eliminate condensate from steam and gas lines. This helps safeguard sensitive instruments like pressure gauges and transmitters from issues like water hammer and corrosion. Produced by Iyle Tube Fittings in South Africa, these pots are built to last, offering outstanding durability and resistance to corrosion even in tough industrial settings. Made from Monel, a nickel-copper alloy, they ensure reliable drainage of condensate and provide thermal isolation, which boosts system accuracy and extends the lifespan of equipment. Their sturdy design allows them to thrive in challenging chemical, marine, and petrochemical environments where standard materials might not hold up.

Monel Type A Condensate Pot with Galvanized Plating Manufacturer South Africa, Monel® Alloy Type B Condensate Pot with Zinc Plating Dealer Johannesburg, Monel Type C Condensate Pots with 4 Ports Dealers Durban, Monel Type A Condensate Pots with 2 Ports Exporter In Germiston, UNS N04400 Type B Condensate Pots Exporter In Gqeberha, Monel Type C Condensate Pot with Zinc Plating Exporter In South Africa, Cape Town.

Monel consists primarily of 65–70% nickel and 20–29% copper, giving it remarkable resistance to seawater, acidic substances, and alkalis. With tensile strengths between 480 and 620 MPa, Monel boasts impressive mechanical strength and toughness, even under high-pressure and high-temperature conditions. Its ability to resist pitting, crevice corrosion, and stress corrosion cracking makes it a great choice for long-term exposure to aggressive process fluids. Monel condensate pots meet ASTM B165 and ASME standards, ensuring they deliver quality and durability in demanding service conditions.

Monel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Chemical Compositions Of Monel Alloy Condensing Pot

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel Alloy Condensing Pot	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min

Sizing Of Monel Alloy Condensing Pot

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Top Monel Condensate Pots Manufacturing Company in South Africa

Monel Condensate Pots are widely utilized in oil and gas refineries, chemical processing facilities, offshore platforms, and marine industries. They play a crucial role in protecting instrumentation within steam systems and process lines by effectively separating condensate from live steam, which helps prevent damage and ensures accurate pressure readings. Thanks to their corrosion resistance and mechanical strength, they are perfect for harsh environments, whether saline, acidic, or otherwise challenging. Plus, they are easy to install and maintain, making these condensate pots a valuable addition to any system, contributing to safer and more reliable operations.

Types of Monel Condensate Pots

Monel Condensate Pot Type A Price in South Africa, Monel Type B Condensate Pot with Red Oxide Coated Manufacturer Supplier in Johannesburg, Monel Condensate Pot Type C Manufacturer in Durban, Monel® Alloy Type A Condensate Pot with Red Oxide Coated Price in Germiston, K500 Monel Condensate Pots Type B Manufacturer in Gqeberha, 400 Monel Type C Condensate Pot Dealer In South Africa, Cape Town.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Monel Condensate Pots Supplier in South Africa, Cape Town

Iyle Tube Fittings is a leading supplier and stockist of premium Monel Condensate Pots in South Africa, Cape Town. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Monel Condensate Pots Uses

Monel condensate pots are widely used in various industrial applications due to their exceptional corrosion resistance and durability. They are commonly utilized in steam systems to collect and separate condensate, preventing water hammer and improving system efficiency. In the chemical processing industry, they serve as reliable vessels for handling corrosive fluids. Additionally, Monel condensate pots are ideal for marine applications, where exposure to saltwater and harsh conditions is prevalent. Their robust design also makes them suitable for power generation, ensuring optimal performance and longevity in demanding environments.
